1958
Interactive 3D model · Lotus 16
02/24
3D model preview
The viewer starts only on request to reduce data transfer and energy use.
Drag to rotate
Wheel or pinch to zoom
Full screen
Guided route
01
Chapman treated every component as an opportunity to remove weight and frontal area. The engine was inclined inside a narrow spaceframe, producing a car whose delicacy anticipated the Lotus philosophy even before the team adopted rear-engine architecture.
02
The 16 was fragile and arrived just as rear-engined cars were changing Formula 1, yet it established the visual and technical daring that would soon make Lotus a reference point for the sport.
Archive provenance
Lotus 16
Sources & credits
Model correspondence
Matching source
The source names the same car as this exhibit. The geometry is the creator's reconstruction, not an official scan.
This non-official historical visualization uses vecarz's model under CC BY 4.0. Its geometry is the creator's reconstruction rather than an official scan; the displayed marks belong to their respective owners.
